Gooseneck fixed ball
Monoblock fixed ball
Removable horizontal ball
Mixed ball-bolt Gooseneck fixed ball CITROEN Relay Van 2016 - EE0633
This type of ball adapts to the aesthetics of your CITROEN Relay .
Supplied with ball cover.
Technical Data
Manufacture year
from 02/2011 until 06/2024
Ball tope
Gooseneck fixed ball
Regulations
CE
Bumper cut out
No
Assembly Time
Between 60' - 90'
MTM
3392 Kg May vary depending on vehicle model
S Value (Imposed load)
150 Kg
D Value
16,9 kN
Brand: Lafuente ®
EAN: 8435380103966
Code: EE0633
Stock:
Yes
Add an Electrical Kit for CITROEN Relay Van 2016
| Universal Electronic Kits They allow the assembly of the electrical installation of the towbar in practically any model of vehicle, avoid error messages on the vehicle information screen, faults due to overload in the electrical system and adapt the different lighting methods used in the rear lights of the vehicle. |
||||
|---|---|---|---|---|
| DCR 7 poles KSK007E2 | 87 € | Add to the Towbar | ||
| DCR 7 poles KSK007 | 97 € | Add to the Towbar | ||
| DCR 13 poles KSK004E | 110 € | Add to the Towbar | ||
| DCR+ 7 poles KSK008A | 117 € | Add to the Towbar | ||
| DCR 13 poles KSK004 | 120 € | Add to the Towbar | ||
| DCR+ 13 poles KSK009A | 135 € | Add to the Towbar | ||
| Specific Electronic Kit They reduce assembly time to a minimum. They include the original connectors, all the components necessary for installation and detailed assembly instructions with step-by-step pictograms. |
||||
|---|---|---|---|---|
| Specific electric kit 13 poles KD130010 | 225 € | Add to the Towbar | ||
| Specific electric kit 7 poles KD070010 | 259 € | Add to the Towbar | ||
Monoblock fixed ball CITROEN Relay Van 2016 - EE0640
It's the classic fixed ball for your CITROEN Relay , is mostly incorporated in commercial and off-road vehicles.
Technical Data
Manufacture year
from 02/2011 until 06/2024
Ball tope
Monoblock fixed ball
Regulations
CE
Bumper cut out
No
Assembly Time
Between 60' - 90'
MTM
3018 Kg May vary depending on vehicle model
S Value (Imposed load)
150 Kg
D Value
15,9 kN
Brand: Lafuente ®
EAN: 8435380102921
Code: EE0640
Stock:
Yes
Add an Electrical Kit for CITROEN Relay Van 2016
| Universal Electronic Kits They allow the assembly of the electrical installation of the towbar in practically any model of vehicle, avoid error messages on the vehicle information screen, faults due to overload in the electrical system and adapt the different lighting methods used in the rear lights of the vehicle. |
||||
|---|---|---|---|---|
| DCR 7 poles KSK007E2 | 87 € | Add to the Towbar | ||
| DCR 7 poles KSK007 | 97 € | Add to the Towbar | ||
| DCR 13 poles KSK004E | 110 € | Add to the Towbar | ||
| DCR+ 7 poles KSK008A | 117 € | Add to the Towbar | ||
| DCR 13 poles KSK004 | 120 € | Add to the Towbar | ||
| DCR+ 13 poles KSK009A | 135 € | Add to the Towbar | ||
| Specific Electronic Kit They reduce assembly time to a minimum. They include the original connectors, all the components necessary for installation and detailed assembly instructions with step-by-step pictograms. |
||||
|---|---|---|---|---|
| Specific electric kit 13 poles KD130010 | 225 € | Add to the Towbar | ||
| Specific electric kit 7 poles KD070010 | 259 € | Add to the Towbar | ||
Removable horizontal ball CITROEN Relay Van 2016 - EE1633
It is easily disassembled and assembled by means of a handle that drives an eccentric shaft. It is a system designed by Lafuente ® that meets demanding security requirements, and that offers excellent aesthetics and great utility in its CITROEN Relay . It is supplied with a bag to store the ball, gloves, dust cap and ball cover.
Technical Data
Manufacture year
from 02/2011 until 06/2024
Ball tope
Removable horizontal ball
Regulations
CE
Bumper cut out
No
Assembly Time
Between 60' - 90'
MTM
3392 Kg May vary depending on vehicle model
S Value (Imposed load)
150 Kg
D Value
16,9 kN
Brand: Lafuente ®
EAN: 8435380107964
Code: EE1633
Stock:
Yes
Add an Electrical Kit for CITROEN Relay Van 2016
| Universal Electronic Kits They allow the assembly of the electrical installation of the towbar in practically any model of vehicle, avoid error messages on the vehicle information screen, faults due to overload in the electrical system and adapt the different lighting methods used in the rear lights of the vehicle. |
||||
|---|---|---|---|---|
| DCR 7 poles KSK007E2 | 87 € | Add to the Towbar | ||
| DCR 7 poles KSK007 | 97 € | Add to the Towbar | ||
| DCR 13 poles KSK004E | 110 € | Add to the Towbar | ||
| DCR+ 7 poles KSK008A | 117 € | Add to the Towbar | ||
| DCR 13 poles KSK004 | 120 € | Add to the Towbar | ||
| DCR+ 13 poles KSK009A | 135 € | Add to the Towbar | ||
| Specific Electronic Kit They reduce assembly time to a minimum. They include the original connectors, all the components necessary for installation and detailed assembly instructions with step-by-step pictograms. |
||||
|---|---|---|---|---|
| Specific electric kit 13 poles KD130010 | 225 € | Add to the Towbar | ||
| Specific electric kit 7 poles KD070010 | 259 € | Add to the Towbar | ||
Mixed ball-bolt CITROEN Relay Van 2016 - EE3640
It is a mixed 50 mm ball system that also serves for its CITROEN Relay as a bolt for trailers with eye-type towbar. It is normally used for ATVs and vans. Supplied with a ball cover.
Technical Data
Manufacture year
from 02/2011 until 06/2024
Ball tope
Mixed ball-bolt
Regulations
CE
Bumper cut out
No
Assembly Time
Between 60' - 90'
MTM
3018 Kg May vary depending on vehicle model
S Value (Imposed load)
150 Kg
D Value
15,9 kN
Brand: Lafuente ®
EAN: 8435380108565
Code: EE3640
Stock:
Yes
Add an Electrical Kit for CITROEN Relay Van 2016
| Universal Electronic Kits They allow the assembly of the electrical installation of the towbar in practically any model of vehicle, avoid error messages on the vehicle information screen, faults due to overload in the electrical system and adapt the different lighting methods used in the rear lights of the vehicle. |
||||
|---|---|---|---|---|
| DCR 7 poles KSK007E2 | 87 € | Add to the Towbar | ||
| DCR 7 poles KSK007 | 97 € | Add to the Towbar | ||
| DCR 13 poles KSK004E | 110 € | Add to the Towbar | ||
| DCR+ 7 poles KSK008A | 117 € | Add to the Towbar | ||
| DCR 13 poles KSK004 | 120 € | Add to the Towbar | ||
| DCR+ 13 poles KSK009A | 135 € | Add to the Towbar | ||
| Specific Electronic Kit They reduce assembly time to a minimum. They include the original connectors, all the components necessary for installation and detailed assembly instructions with step-by-step pictograms. |
||||
|---|---|---|---|---|
| Specific electric kit 13 poles KD130010 | 225 € | Add to the Towbar | ||
| Specific electric kit 7 poles KD070010 | 259 € | Add to the Towbar | ||
Electric kits
| Universal Electronic Kits |
|---|
| DCR 7 poles KSK007E2 |
| DCR 7 poles KSK007 |
| DCR 13 poles KSK004E |
| DCR+ 7 poles KSK008A |
| DCR 13 poles KSK004 |
| DCR+ 13 poles KSK009A |
| Specific Electronic Kit |
|---|
| Specific electric kit 13 poles KD130010 |
| Specific electric kit 7 poles KD070010 |
