Gooseneck fixed ball
Removable horizontal ball Gooseneck fixed ball PEUGEOT Partner II 2017 - EE0541
This type of ball adapts to the aesthetics of your PEUGEOT Partner .
Supplied with ball cover.
Technical Data
Manufacture year
from 06/2015 until 10/2018
Ball tope
Gooseneck fixed ball
Regulations
CE
Bumper cut out
No
Assembly Time
Between 30' - 60'
MTM
1600 Kg May vary depending on vehicle model
S Value (Imposed load)
108 Kg
D Value
8,85 kN
Brand: Lafuente ®
EAN: 8435380143290
Code: EE0541
Stock:
Yes
Add an Electrical Kit for PEUGEOT Partner II 2017
| Universal Electronic Kits They allow the assembly of the electrical installation of the towbar in practically any model of vehicle, avoid error messages on the vehicle information screen, faults due to overload in the electrical system and adapt the different lighting methods used in the rear lights of the vehicle. |
||||
|---|---|---|---|---|
| DCR 7 poles KSK007E2 | 87 € | Add to the Towbar | ||
| DCR 7 poles KSK007 | 97 € | Add to the Towbar | ||
| DCR 13 poles KSK004E | 110 € | Add to the Towbar | ||
| DCR 13 poles KSK004 | 120 € | Add to the Towbar | ||
| Specific Electronic Kit They reduce assembly time to a minimum. They include the original connectors, all the components necessary for installation and detailed assembly instructions with step-by-step pictograms. |
||||
|---|---|---|---|---|
| Specific electric kit 7 poles KD070023 | 208 € | Add to the Towbar | ||
| Specific electric kit 13 poles KD130023 | 222 € | Add to the Towbar | ||
| If you install a 13-pin Specific Kit and need to have direct current, it may be necessary to install an Auxiliary Kit of +15/+30 Amps. | ||||
| KIT AUX.+15/+30 - M01176 | 60 € | Add to the Towbar | ||
Removable horizontal ball PEUGEOT Partner II 2017 - EE1541
It is easily disassembled and assembled by means of a handle that drives an eccentric shaft. It is a system designed by Lafuente ® that meets demanding security requirements, and that offers excellent aesthetics and great utility in its PEUGEOT Partner . It is supplied with a bag to store the ball, gloves, dust cap and ball cover.
Technical Data
Manufacture year
from 06/2015 until 10/2018
Ball tope
Removable horizontal ball
Regulations
CE
Bumper cut out
No
Assembly Time
Between 30' - 60'
MTM
1600 Kg May vary depending on vehicle model
S Value (Imposed load)
108 Kg
D Value
8,85 kN
Brand: Lafuente ®
EAN: 8435380143740
Code: EE1541
Stock:
Yes
Add an Electrical Kit for PEUGEOT Partner II 2017
| Universal Electronic Kits They allow the assembly of the electrical installation of the towbar in practically any model of vehicle, avoid error messages on the vehicle information screen, faults due to overload in the electrical system and adapt the different lighting methods used in the rear lights of the vehicle. |
||||
|---|---|---|---|---|
| DCR 7 poles KSK007E2 | 87 € | Add to the Towbar | ||
| DCR 7 poles KSK007 | 97 € | Add to the Towbar | ||
| DCR 13 poles KSK004E | 110 € | Add to the Towbar | ||
| DCR 13 poles KSK004 | 120 € | Add to the Towbar | ||
| Specific Electronic Kit They reduce assembly time to a minimum. They include the original connectors, all the components necessary for installation and detailed assembly instructions with step-by-step pictograms. |
||||
|---|---|---|---|---|
| Specific electric kit 7 poles KD070023 | 208 € | Add to the Towbar | ||
| Specific electric kit 13 poles KD130023 | 222 € | Add to the Towbar | ||
| If you install a 13-pin Specific Kit and need to have direct current, it may be necessary to install an Auxiliary Kit of +15/+30 Amps. | ||||
| KIT AUX.+15/+30 - M01176 | 60 € | Add to the Towbar | ||
