LAFUENTE Trailers Series Motorcycles and Quads are designed for easy loading
and unloading, with reliable transportation and safe driving. Systems offer
several trailers to meet all your necesidades.Cubre a wide range of trial
bikes, cross, road, 4x4 quads, competition, etc.
Advantages:Easy loading and unloading, secure fixation of the vehicle load.
Technical Data
- External dimensions:
- 3000 x 1590 mm.
- Box dimensions:
- 2100 x 1270 mm.
- Axle:
- 1 of 500 Kg.
- P.M.A. (maximum authorised mass):
- 500 Kg.
- Wheels:
- 145-13 (inches)
- Material:
- Painted
- Break:
- No
Lafuente Trailers® Motorcycles and Quads series
The Lafuente® trailers of the Motorcycle and Quad series are designed for easy loading and unloading, with reliable transport and without driving risks. We offer several trailer systems that will cover all your needs. It covers a wide range of trial, cross, road motorcycles, 4×4 quads, competition, etc.
Technical characteristics
- Constructed in 60 x 40 x 2 structural tube .
- Steel chassis painted with Bicomponent paint.
- Hot dip galvanized guides.
- Shim made of galvanized steel.
- Removable and adaptable ramp in three positions, one for each guide, easy and quick to position depending on the guide we are going to use.
Advantages
- Easy upload and download.
- Safe attachment of motorcycles and quads to the trailer.
- Great driving reliability.
